Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Working voltage | DC 7.5-24V |
|---|---|
| Peak operating current | H series: 12V/2.0A L series: 12V/700mA S series: 12V/2.5A |
| Working temperature | -30～65℃ |
| Working humidity | 5%-95% RH No condensation |
| Storage temperature | -40～+70℃ |
| IP Level | IP67 |
| Tag protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Working frequency | 840～960 MHz |
| Support work area | China 1，China 2，US, Canada and other regions following U.S. FCC，Europe and other regions following ETSI EN 302，208 with & without LBT regulations，Japan、Korea、Malaysia、Taiwan |
| Output power | H series: Step interval of 1.0dB,+5dBm -+30dBm L series: Step interval of 1.0dB,+5dBm -+25dBm S series: Step interval of 1.0dB, 0dBm -+33dBm |
| Output power flatness | ±0.2dBm |
| Receiver sensitivity | H series: -82dBm L series: -62dBm S series: -82dBm |
| RF port standing wave | ≤1.5 |
| Read distance | F5016-H：0～10 meter F5016-L：0～5 meter F5016-S：0～8 meter |
| Multi tag reading | H series ：≥800tags/s L series ：≥200tags/s S series:≥800tags/s |
| Interface communication speed | 115200bps |
|---|---|
| Working temperature detection | H. S series support |
| Dense Reader Mode DRM | Support |
| Antenna connection protection | Support |
| Return signal acceptance strength RSSI | Support |
| Antenna type | Paired with 6dBi circularly polarized antenna |
| GPIO controller | Input IO port: 2 channels Output IO port: 4 channels |
| Communication interface | RS-232、 Network port，WIFI (optional)，RS-485 (optional), Wiegand 26/34 (optional), Bluetooth (customizable) |
| Buzzer | Yes |
| Appearance design | PC+ABS/ Aluminum alloy shell design |
| Size | 133*133*52mm |
| Weight | 1.25KG |
