Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Sensor | ARM-COTEXM3 |
|---|---|
| Air interface protocol | EPC global UHF Class 1 Gen 2/ISO 18000-6C |
| Working frequency | 840～960MHz（ Default frequency band 920～925MHz） |
| Supported regions | China, Europe, United States, South Korea, Japan, etc. |
| Working voltage | DC12V |
| Working current | H series ＜2.5A L series ＜700mA |
| Standby current | ＜50mA |
| Output power | Software adjustable: The step interval is 1.0dB, and each channel can be individually adjusted from+5dBm to 30dBm |
| Maximum receiving sensitivity | -82dBm |
| Operation temperature | -25℃～+65℃ |
| Working humidity | ≤95%（+25℃） |
| Storage temperature | -30℃～+70℃ |
|---|---|
| DRM mode | Support |
| RSSI | Support |
| High temperature automatic protection | Support |
| External watchdog | Support |
| GPIO port | Input IO port: 2 channels Output IO port: 4 channels |
| Buzzer | Support |
| LED indicator light | Power indicator light: 1 LED (red) Status indicator light: 1 LED (green) |
| Communication function | Mini USB interface,Network port,RS-485,WIFI (optional) Bluetooth (customizable),232 serial port,Wiegand |
| Size | 400X300X35mm |
