Technical Parameters
| Working voltage | DC+9V～+26V（default +12V） |
|---|---|
| Stand-by current | ＜120mA |
| Working current | ＜1.0A |
| Operating temperature | -20℃～+60℃ |
| Working humidity | 5%RH-95%RH（No condensation） |
| Storage temperature | -20℃～+85℃ |
| tag protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Working frequency | 840～960 MHz(default 920MHz-925MHz) |
| Support work area | China 2（option： China 1 , Europe , USA ,Japan or Korea） |
| Output Power | +15dBm-+25dBm |
| Output power flatness | 1.0dB |
| Receive sensitivity | ±0.2dB |
| RF port standing wave | -62dBm |
| Maximum reading distance | ≤1.5 |
|---|---|
| Tag reading success rate | ≥3.5 meters (reading distance, tag angle, tag type and application environment vary close) |
| Interface communication rate | ≥98% |
| Antenna monitoring | Default 115200bps (other rates can be set: 38400bps, 9600bps, etc. |
| Acceptance Strength RSSI | Support |
| Antenna type | Support |
| Communication interface | Paired with 3dBi ceramic antenna |
| Device interface | Small 5557 female connector (other connectors can be customized) |
| Buzzer | Yes |
| RTC | Yes |
| Material | ABS (base plate is metal) |
| Exterior color | Black |
| Size | 155mm*117.5mm*25mm |
