Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Working voltage | DC 12V |
|---|---|
| Peak operating current | H series ：2.0A L series：700mA S series：2.5A |
| Work temperature | -20～65℃ |
| Working humidity | 5%-95% RH No condensation |
| Storage temperature | -30～+70℃ |
| Tag protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Working frequency | 840～960 MHz |
| Support work areas | China 1，China 2，US, Canada and other regions following U.S. FCC，Europe and other regions following ETSI EN 302 208 with & without LBT regulations，Japan、 Korea、 Malaysia、 Taiwan |
| Output power | H series: Step interval of 1.0dB,+5dBm -+30dBm L series: Step interval of 1.0dB,+5dBm -+25dBm S series: Step interval of 1.0dB, 0dBm -+33dBm |
| Output power flatness | ±0.2dBm |
| Reception sensitivity | H series：-82dBm L series：-62dBm S series：-82dbm |
| RF port standing wave | ≤1.5 |
| Read distance | F5019-H:0～23 meter F5019-L:0～8 meter F5019-S:0～23 meter |
| Multi tag reading | H series：≥800tags/s L series：≥200tags/s S series：≥800tags/s |
| Interface communication speed | 115200bps |
|---|---|
| Working temperature detection | Support |
| Dense reader mode DRM | Support |
| Antenna connection protection | Support |
| Return signal acceptance strength RSSI | H series: Supports L series: Supports S series: Supports |
| Antenna type | Paired with 9dBi circularly polarized antenna |
| Communication interface | Standard: RS-232, RJ45 (100Mbps Ethernet interface) Customizable: RS-485, 4G, WIFI, Bluetooth |
| Buzzer | yes |
| Appearance design | Design of ABS Engineering Plastic Box Shell |
| Size | 270*270*75mm |
| IP address | IP65 |
| Weight | 2.8KG |
