Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Working voltage | DC 12V |
|---|---|
| Peak operating current | S series：2.5A |
| Working temperature | -20～65℃ |
| Working humidity | 5%-95% RH No condensation |
| Storage temperature | -30～+70℃ |
| Tag protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Work frequency | 840～960 MHz |
| Output power | Software adjustable: S series: Step interval of 1.0dB, 0dBm -+33dBm |
| Output power flatness | ±0.2dBm |
| Receiver sensitivity | S series ：-82dbm |
| RF port standing wave | ≤1.5 |
| Read distance | F5018-S：0～13 meter |
| Multi tag reading | H series ：≥800 tags/s L series：≥200 tags/s M series:≥800tags/s |
| Interface communication speed | 115200bps |
| Working temperature detection | Support |
|---|---|
| Dense Reader Mode DRM | Support |
| Antenna connection protection | Support |
| Return signal acceptance strength RSSI | H series: Supports L series: Supports |
| Antenna type | Paired with 8dBi circularly polarized antenna |
| Communication interface | Standard: RS-232, RJ45 (100Mbps Ethernet interface) Customizable: RS-485, 4G, WIFI, Bluetooth |
| Buzzer | Yes |
| Appearance design | ASA Engineering Plastic Box Shell Design |
| Dimension | 190*190*54mm |
| IP Level | IP65 |
| Weight | 0.74KG |
