Features
.png)
Android 10/13
.png)
5.5-inch HD
.png)
IP65 Sealing
.png)
All-in-one UHF Design
.png)
Octa-core 64 bit 2.0 GHz
.png)
7.6V4000mAh
.png)
1.2m Drop Proof
Functions
.png)
UHF RFID(Impinj E710 Chip)
.png)
Front & Rear Dual Camera
Dual-band WIFI
.png)
Barcode Scanning(Optional)
.png)
NFC(Optional)
.png)
GPS
Physical Characteristics
| Dimensions | 211.5 mm x 136.0 mm x 16.3 mm |
|---|---|
| Weight | 700g（inculding battery） |
| Display | 8 inches, screen resolution 1280 x 800/1920 x 1200（option） |
| Touch Panel | Multi-touch panel |
| Battery capacity | Rechargeable lithium polymer battery 3.8V 9000 mAh， standby time＞ 500 hours，Working hours>10 hours (depending on usage and network environment)，Charging time 3-4 hours (using standard power adapter and data cable) |
| Speaker volume | >90db（test distance 10cm） |
| Interfaces | USB Type-C Support OTG，USBA x2(Option） |
| Card slot | SIM x 1，SIM/TF x1，Option PSAM x2 |
| Audio | Speaker, microphone, earpiece |
| Keypad | 1 power button, 1 side volume button, custom button x2 |
| Sensors | Gravity sensor, gyroscope, acceleration sensor |
Communication
| WLAN | Dual-band 2.4GHz / 5GHz, Support IEEE 802.11ac/a/b/g/n/d/e/h/i/j/k/r/v protocol |
|---|---|
| WWAN | 2G: GSM（850/900/1800/1900MHz） 3G: WCDMA（850/900/1900/2100MHz） 4G: FDD:B1/B3/B4/B7/B8/B12/B20 TDD:B38/B39/B40/B41 |
| Bluetooth | 5.0+BLE |
| GNSS | GPS/Beidou/GLONASS/Galileo, supports AGPS |
Developing Environment
| Operating System | Android 10/13 |
|---|---|
| SDK | SANRAY Software Development Kit |
| Language | Simplified Chinese, Traditional Chinese, English, Korean, Japanese,Malaysian,etc. |
Performance
| CPU | Eight core 64 bit 2.0GHz high-performance processorr |
|---|---|
| RAM+ROM | 4GB+64GB/6GB+128GB |
| Expansion | Micro SD（TF）Card expandable up to 256GB |
User Environment
| Operating Temp | -20℃ - 55℃ |
|---|---|
| Stroage Temp | -40℃ - 70℃ |
| Humidity | 5%RH--95%RH(no condensation) |
| Drop Specification | 6 sides supports 1.2 meters drops on the marble within the operating temperature |
| Seeling | IP65 |
Barcode Scanning
| 2D lmager Scanner | Honeywell N6703 N5703 N6602-W2 |
|---|---|
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleave 2 of 5,Discrete 2 of 5, Chinese 2 of 5, Coda bar, MSI RSS : Postal barcode: USPS Planet, USPS POSTNET, China Post, Kore Post, Australian Postal, Japan Postal, Dutch Postal (KIX), Royal Mail, Canadian Customs |
| 2D Symbologles | PDF417, MicroPDF417, Composite, RSS, TLC-39,Data matrix, QR code, Micro QR code, Aztec, Maxi Code, Han Xin |
| Note | *This function is optional |
UHF RFID
| Engine | Nation Rfid N6801/Impinj E710（Either-or） |
|---|---|
| Frequency | 865-868 MHz / 902-928 MHz / 920-925 MHz |
| Distance | 0-13m |
| Note | * Ranges and rates depend on tags and environment |
SIM
| Supported Specifications | SIM x 1，SIM/TF x1，Option PSAM x2 |
|---|
Camera Standard
| Front Camera | 5-megapixel color camera |
|---|---|
| Rear Camera | 13 megapixel color camera (optional 20 megapixel), supporting autofocus and flash |
NFC
| Frequency | 13.56MHz |
|---|---|
| Protcol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2 |
| Range | 2-5cm |
| Note | * This function is optional |
