Performance
| size | 228*228*68mm |
|---|---|
| Weight | 1.78kg |
| Overall Power Consumption | 2W |
| power | DC12V |
| Installation method | Installation of clamps |
| operation temperature | -25℃～65℃ |
| storage temperature | -30℃～70℃ |
| Working humidity | 5%～95%～（No condensation） |
| IP lever | IP65 |
Communication
| communication interface | RS232, 10/100M adaptive Ethernet interface Wiegand 26/34 (optional), RS-485 (customizable) |
|---|---|
| I/O interface | 2-channel input interface, 4-channel output interface (optional) |
| Scalable wireless module | 802.11 module, full network 4G module |
| UPGRADE | Support serial port upgrade |
| Serial communication parameters | Adjustable baud rate (default 230400bps) |
| Application software platform | Provide software development kit (SDK) and API |
Label operation
| Support tag operation | proprietary protocol |
|---|---|
| Support tag working mode | Active tags |
| Read distance | 5～350m （Depends on the output power of the antenna and tag） |
| Recognition speed | 500 tags per second (ID number only) |
Operating
| Operating Frequency | 2.4～2.483G |
|---|---|
| Signal attenuation | Software adjustable: 0-63dbm (the larger the value, the greater the attenuation) |
| Receiver sensitivity | -95dBm |
| Communication speed | 1Mbit/s |
| Antenna gain | 12dBi |
| Identify angles | directional（Hor:33°/ Ver:36°） |
| Polarization mode | Vertical polarization |
