Features
2.45G
IP65 Sealing
7.6V4000mAh
Physical
| Tag characteristics | Thin type |
|---|---|
| Sensing mode | Active launch once per second |
| Material | ABS,White |
| Size | 86*55*4mm |
| Industrial grade | IP67 |
| Installation method | Carry |
2.4G
| Signal modulation | GFSK |
|---|---|
| Communication rate | 1Mbit/s |
| Output Power | 7dbm |
Electrical
| Quiescent Current | 3uA |
|---|---|
| Peak current | 《25mA |
| Average current | 《20uA |
| Battery model | CR3032 |
| Battery capacity | 500mA |
| Service life | More than two years |
Environmental
| Operating temperature | -20℃~+45℃ |
|---|---|
| Storage temperature | -30℃~+65℃ |
